Typical Properties | Average Result |
Uncured: | |
Appearance* | White |
Viscosity, within 15 minutes of catalyzation* | 36,000 cP (36,000 mPas) |
Viscosity, 2 hours after catalyzation* | 50,000 cP (50,000 mPas) |
Tack-Free Time* | 13 hours |
Cured: 15 minutes at 150°C (302°F) | |
Specific Gravity* | 2.34 |
Durometer, Type A* | 65 |
Tensile Strength* | 180 psi (1.2 MPa) |
Elongation* | 50% |
Lap Shear Strength (primed with SP-270)* | 120 psi (0.8 MPa) |
Thermal Conductivity* | 0.95 W/(mK)(23 x 10-4 cal/(cm sec°C)) |
Volatile Content (1 hr at 275°C) | 0.35 % |
Volume Resistivity | 3.4 X1013 |
Dielectric Strength | 465 V/mil (18.1 kV/mm) |
Dielectric Constant, 100 Hz | 4.9 |
Dielectric Constant, 1 kHz | 4.9 |
Dissipation Factor, 100 Hz | 0.003 |
Dissipation Factor, 1 kHz | 0.002 |
Coefficient of Linear Expansion (-70°C to 200°C) | 200µm/(m°C) |
Glass Transition Temperature (Tg) | -98°C |
Ion Content, Na | < 6ppm |
Ion Content, K | < 3ppm |
Ion Content, Cl | < 5ppm |
*Properties tested on a lot-to-lot basis. Do not use the properties shown in this technical profile as a basis for preparing specifications. Pleasecontact NuSil Technology for assistance and recommendations in establishing particular specifications.
Recommended Primer SP-270
Note: Some bonding applications may require the use of a primer.
Packaging
50 Gram Kit
200 Gram Kit
500 Gram Kit
Warranty
12 Months
