BIOMATERIALS MEDICAL IMPLANT GRADE SILICONES
| PRODUCT NUMBER |
VISCOSITY cP (mPa·sec) |
WORK TIME @ 25°C |
DUROMETER TYPE A |
TENSILE psi (MPa) |
STRESS @ STRAIN psi (MPa) @ % |
ELONGATION % |
TEAR ppi (kN/m) |
MIX RATIO |
|---|---|---|---|---|---|---|---|---|
| MED-6221 | 4,200 | 7 h | 20 | 255 (1.8) | - | 170 | - | 1:1 |
| MED-6215 | 3,800 | 5 h | 50 | 1,250 (8.62) | - | 100 | - | 10:1 |
| MED-4286 | 6,350 | 17.5 h | 55 (000) | 45 (0.31) | 8 (0.06) @ 200 | 475 | - | 1:1 |
| MED-6210 | 16,000 | 4 h | 50 | 930 (6.41) | - | 140 | 35 (6.17) | 1:1 |
| MED2-4420 | 22,000 | 3 m | 20 | 585 (4.4) | - | 500 | - | 1:1 |
| MED3-4420 | 91,250 | 15 m | 23 | 1,000 (6.9)? | - | 600 | 75 (13.2) | 1:1 |
| MED4-4420 | 23,250 | 35 m | 17 | 700 (4.83) | - | 600 | 35 (6.17) | 1:1 |
| MED-6219 | 25,500 | 2.5 h | 75 | 1,300 (8.97) | - | 65 | 35 (6.17) | 1:1 |
| MED-6385 | 45,000 | 7.5 m | 45 | 500 (3.4) | - | 175 | - | 100:0.5 |
| MED-6820 | 66,000 | 4.5 h | 40 | 670 (4.62) | - | 210 | 40 (7.05) | 1:1 |
| MED-6233 | 73,500 | 52 h | 50 | 740 (5.1) | - | 380 | 80 (14.11) | 1:1 |
| MED-4211 | 95,600 | - | 25 | 685 (4.7) | - | 530 | - | 10:1 |
| MED-4244 | 130,000 | 4 h | 40 | 865 (5.97) | 480 (3.3) @ 200 | 350 | 150 (26.46) | 10:1 |
